General
Overview
This document provides a comprehensive guide to the device, covering its model code structure, technical specifications, and safe usage. It explains the intended applications, product designations, and relevant manufacturer information. Technical details about image sensors, processors, and storage are outlined to highlight the device's performance. Safety instructions and warning symbols are also described to ensure safe operation and handling.
Model Code Reference
Model Code Description Table
| Series |
Shutter |
Resolution |
Compute Module |
| C7 |
G - Global |
X - X Megapixel |
N - Jetson Nano |
|
R - Rolling |
|
NX - Xavier NX |
|
|
|
ON - Orin Nano |
|
|
|
ONX - Orin NX |
Product Number Reference
Intended use
Mount the device on a aluminum profile, using the 4 M4 threaded holes on the back
of the device. Then connect the device to a suitable power supply (see section Installation) using a matching cable. Please
follow the subsequent sections for rated values and electrical safety
considerations!
Specifications
Designation
| Designation |
Abbreviation |
| C7 Edge Camera Module |
ECM |
Environmental conditions
| Property |
Value |
| Operating temperature |
-20°C ... 40°C |
| Permissible humidity |
< 95% RH (non-condensing) |
| Degree of protection |
IP67 with protection tube P/N 1.23.10.21.08 |
Housing
| Property |
Description |
| Lens holder |
C-Mount |
| Cooling |
Passive |
| Dimensions |
107.8 mm x 95.0 mm x 67.0 mm |
| Weight |
630 g |
| Mounting |
4 x M4 |
Image sensor
| Image sensor |
Sony IMX540 |
| Family |
Pregius S |
| Shutter type |
Global Shutter |
| Color |
Mono / Bayer |
| Resolution |
5320 x 4600 (24.4 MP) |
| Sensor size |
1.2" |
| Max. source framerate |
21 FPS |
| Pixel pitch |
2.74 µm |
| Quantum efficiency |
68 % |
| Absolute sensitivity threshold |
2.9 e |
| Saturation capacity |
9400 e |
Processor
|
NVIDIA® Jetson Orin NX™ 16GB |
| CPU |
8 Core ARM® Cortex®-A78AE v8.2 |
| RAM |
16 GB 128-bit LPDDR5 |
| GPU |
NVIDIA® Ampere™ |
| CUDA Cores |
1024 |
| Tensor Cores |
32 |
| Power |
10W - 25W |
storage
Manufacturer
Lifting and carrying instructions
The device weighs less than 1 kg. It is a system with a camera. Therefore, be
careful when touching the lens and use the designated interface to mount the
system. Do not drop the device! Only carry the device around when it is
switched off and has cooled down, e.g. by grabbing it at the heat sink.
Explanation of the warnings and warning symbols attached to the device
| Symbol |
Description |
 |
Warning for hot surface |
Safety instructions
- Do not drop the device.
- Only carry the device around when it is switched off and has cooled down.
